Parameter
**Product Weight:** 745g (module) / 1.3Kg (including water collection bucket)
**Interface Types:** SKYPORT V2.0/E-PORT/TYPE-C
**Control Method:** DJI Pilot
**System Power:** 30W
**Operating Temperature:** -20℃ to 60℃
**Sampling Capacity:** 1 L
**Control Distance:** Consistent with the communication range of the drone
**Feedback:** Work status display / Depth display
**System Tension:** 35N
**Installation Method:** Quick-installation with belly clip
**PHUB:** Supported
**Reel Length:** 10m
**Reel Speed:** 0.1m/s (adjustable)
**Smart Functions:** Automatic limit / Over-temperature protection / Short-circuit protection / Anti-tangle / Emergency disconnection function / Mechanical tension detection / Depth sampling
Function
1. The drone automatically recognizes the water sampler, ready to use upon startup.
2. Depth-specific sampling with emergency fuse and tension detection functions.
Compatible Models
DJI M350/300
